SRAM EAGLE NX 1x12 Speed with Derailleur options 4 Piece Kit

Find out why everyone who has a 1X system loves it!

SRAM Eagle NX the affordable Eagle 12 Speed Group that works with common rear cassette hubs you probably already have on your bike

The NEW 11-50 NX Eagle Cassette works on most 8/9/10/11 Speed Cassette Rear Hubs

(Fits SRAM / Shimano / and most standard rear cassette splined hubs too...NOT XD type Hub)

SRAM NX Eagle X-Actuation Trigger Shifter:
New NX Eagle trigger shifter means on-demand gear selection throughout the entire wide range Eagle cassette. The massive range means you never have to worry about having the right gear for the terrain. NX Eagle means easy, intuitive shifting every time for every rider.

Speeds: 12 Speed
Compatibility: 1x12 SRAM
Eagle Technology creates a smoother and more precise shifting system with exceptional reliability.
Also available as a E-MTB specific Eagle shifter option limiting the pull lever to a single engagement.
Compatible with Matchmaker X clamp
Material: Aluminum / Plastic
Hardware: Stainless Steel bolts, Discrete clamp
Advertised Weight ~ 112g
Discrete clamp
X-ACTUATION: Developed specifically for SRAM 1x, X-ACTUATION keeps shifting sharp and consistent across the entire cassette.
Zero Loss: ZeroLoss simply means, well, zero loss when you push on the lever, for an upshift or down shift, the cable is engaged instantly zero loss of movement. There is no middle-ground where you're waiting for the shift to come. Gear changes are instant and precise.

SRAM Eagle NX 12 Speed Chain:

The basis of every Eagle drivetrain is its chain and the NX Eagle chain is designed and manufactured using the genuine SRAM Eagle architecture, so it is fully compatible with every other component in the Eagle ecosystem. The NX Eagle chain features solid pin construction, Eagle PowerLock and smooth, efficient shifting that you can count on every time out.

Speeds: 12 Speed
Eagle PowerLock chain connector with FLOW LINK technology provides better chain-guiding and increased longevity.
Unique features and design also provide significantly improved wear resistance on Eagle cassettes and rings.
Closing Link: Eagle PowerLock
Material: Steel
Compatibility: 12 Speed SRAM
Advertised Weight ~ 275g (126 Links)
PowerLock: SRAM chain engineers developed PowerLock as a tool free, sure, and consistent way to connect our chains. While PowerLock does not require special tools for install, the especially tight tolerances of 10-, 11- and 12-speed drivetrains mandate that each PowerLock is good for a one-time application only.
Flow Link: Ultra-smooth chain inner-plates are completely devoid of square edges, resulting in a chain that engages the cassette and chainring with far less friction, for quieter performance and better wear life. The design allows a narrower overall profile that can withstand greater angles, and also allows for a flatter outer-plate, which means more consistent chain riveting and enhanced overall strength.
X-Sync 2: The next evolution of SRAM X-SYNC technology. The aggressive teeth design provides better chain retention for a smoother, more efficient pedal feel. With a focus on long wear-life, the X-SYNC EAGLE design reduces friction and the accumulation of mud, grit and grime.

SRAM NX Eagle PG-1230 12 Speed 11-50t Cassette:

NEW 11-50 NX Eagle Cassette works on most 8/9/10/11 Speed Cassette Hubs

Ride anywhere with the wide-range PG-1230, 11- to 50-tooth Eagle cassette. The NX cassette gives riders every bit of the climbing range that the Eagle ecosystem affords with a simple upgrade to splined-drive body wheels. The PG-1230 is the only Eagle cassette designed to be durable enough to withstand the increased demands of E-MTB applications and a perfect solution to heavy-duty use and abuse.

Speeds: 12
Cassette Cogs: 11-13-15-17-19-22-25-28-32-36-42-50
Range: 11-50t
Compatible with eBike
Compatible with 8, 9, 10, 11-speed splined driver bodies.
This PG-1230 cassette is an integral part of the SRAM Eagle drivetrain Ecosystem.
Wide 11-50t gear range a perfect fit for any ride with optimized gear steps across entire range.
Material: 8 lightweight, stamped steel cogs and 4 high-strength steel cogs pinned onto an aluminum spider
Advertised Weight ~ 615g
PowerGlide II: Cassette technology optimized for offroad. More reliable. More durable. Better performing, thanks to an optimal tooth profile and shift ramp design for quick and positive index shifting. Now go climb a mountain.

You Choose from three different Derailleurs:

1. SRAM NX EAGLE X-HORIZON Rear Derailleur:
This new NX Eagle derailleur features the proven SRAM 1x-specific X-HORIZON design. The larger, 14-tooth X-SYNC lower pulley easily facilitates 11- to 50- and 10- to 50-tooth cassette capacity, and also adds to NX Eagle overall smooth-pedaling feel. The Type-3 ROLLER BEARING CLUTCH provides quiet, consistent performance and durability. Nice!

Speeds: 12 Speed
Completely new rear derailleur incorporating our proven X-HORIZON design and Type-3 ROLLER BEARING CLUTCH technology.
Eagle ecosystem-engineered mounting system and CAGE LOCK positioning add robustness.
Eagle pulley technology provides greater efficiency, crisper shifting and quieter operation.
Speeds: 12
Material: Aluminum / Steel
Weight ~ 338g
Black
Compatibility: 1x12 SRAM
Hardware: Stainless Steel
Bearings: Sealed Cartridge Bearings
Cage Size: Long
Pivot Design: Horizontal Parallelogram design
Max Tooth: 50t
Pulleys: 12-tooth X-SYNC pulley wheels
Also compatible for e-bike applications
CAGE LOCK: With CAGE LOCK technology in the rear derailleur, wheel removal and installation as well as chain installation becomes faster and simpler. Just pushing the cage forward to create slack and lock it into place.
ROLLER BEARING CLUTCH: ROLLER BEARING CLUTCH rear derailleurs deliver maximum drivetrain stability even through the most punishing terrain. With ROLLER BEARING CLUTCH technology, derailleur bounce and chain slap are eliminated without sacrificing precision.
X-ACTUATION: Developed specifically for SRAM 1x, X-ACTUATION keeps shifting sharp and consistent across the entire cassette.
X-HORIZON: The X-HORIZON rear derailleur straight parallelogram design limits all movement to the horizontal axis, which makes ghost shifting impossible while also reducing shift force. For quicker, more exact shifting, the large upper pulley offset design maintains a constant chain gap across all gears.
X-SYNC 2: X-SYNC 2 Eagle is the next evolution of SRAM X-SYNC technology. The aggressive teeth design provides better chain retention for a smoother, more efficient pedal feel. With a focus on long wear-life, the X-SYNC EAGLE design reduces friction and the accumulation of mud, grit and grime.

2. SRAM SX EAGLE Rear Derailleur:

The SX Eagle derailleur features the proven SRAM 1x-specific X-HORIZON design and easily facilitates 11-50t and 10-50t cassette capacity, providing quiet, consistent performance and durability

SX Eagle derailleur is your entry point to the SRAM Eagle Ecosystem
A full featured Eagle derailleur, compatible with the Eagle Colorsystem
X-SYNC pulley technology provides greater efficiency, crisper shifting and quieter operation
Cage Lock offers discovery-level riders easy trail side wheel removal
Color: Black
Largest Cog: 50
Rear Derailleur Mount Type: 10x1 Standard
Chain Wrap Capacity (teeth): 40
Cage Length: Long
Rear Der/Shifter Compatibility: SRAM X-Actuation
Drivetrain Speeds: 12

3. SRAM GX EAGLE Rear Derailleur:

The GX Eagle Rear Derailleur gets the job done with a thoughtfully designed cage architecture that improves chain management.

Mounting system and re-positioned Cage Lock offer greater durability
Sealed cartridge pulley bearings
Backwards compatible, works with both 10-50t and 10-52t cassettes
Updated cage architecture provides better chain retention and precise shifts
Comes in GX Eagle master colorway as part of Eagle Colorsystem and goes with all colors of Eagle cassettes & chains
Color: Lunar
Largest Cog: 52
Rear Derailleur Mount Type: 10x1 Standard
Chain Wrap Capacity (teeth): 42
Cage Length: Long
Rear Der/Shifter Compatibility: SRAM X-Actuation
Drivetrain Speeds: 12
